| MODEL |
VPWM48200 |
| Rate voltage(Vdc) |
51.2 |
| Rate capacity(AH) |
200 |
| Energy storage(KWH) |
10.24 |
| Cycle life |
≥6000 cycles to 80% DOD |
| Months self discharge |
≤2% |
| Effciency of charge |
100% at 0.2C |
| Effciency of discharge |
96-99% at 1C |
| Charge voltage |
58-4 |
| Charge current(A) |
40 |
| Max Charge current(A) |
120 |
| Charge temperature |
0℃ to 45℃(32F to 113F)@60±25% Relative Humidity |
| Discharge temperature |
-20℃ to 60℃(-4F to 140F)@60±25% Relative Humidity |
| IP class |
IP60 |
| Material system |
LIFePO4 |
| Case material |
Metal |
| Pack Dimensions L*W*H(mm) |
590*376*245 |
| Package Dimension L*W*H(mm) |
685*470*350 |
| Net Weight(KG) |
82 |
| Gross Weight(KG) |
85 |
| Protocol(Optional) |
CANBus/RS485/RS232 |
