| MODEL |
VPWM48100HV |
VPWM48150HV |
VPWM48200HV |
| Rate voltage(Vdc) |
51.2 |
51.2 |
51.2 |
| Rate capacity(AH) |
100 |
150 |
200 |
| Energy storage(KWH) |
5.12 |
7.68 |
10.24 |
| Cycle life |
≥6000 cycles to 80% DOD |
| Months self discharge |
≤2% |
| Effciency of charge |
100% at 0.5C |
| Effciency of discharge |
96-99% at 1C |
| Charge Voltage |
58.4V |
| Charge current(A) |
20 |
30 |
40 |
| Max Charge current(A) |
100 |
120 |
120 |
| Charge Temperature |
0℃ to 45℃(32F to 113F)@60±25% Relative Humidity |
| Discharge temperature |
-20℃ to 60℃(-4F to 140F)@60±25% Relative Humidity |
| IP class |
IP60 |
| Material system |
LIFePO4 |
| Case material |
Metal |
| Pack Dimensions L*W*H(mm) |
590*410*155 |
680*545*150 |
590*376*245 |
Package Dimension L*W*H(mm)
|
600*485*250 |
760*625*240 |
685*470*350 |
Net Weight(KG)
|
50 |
72 |
82 |
Gross Weight(KG)
|
53 |
75 |
85 |
Protocol(Optional)
|
CANBus/RS485/RS232 |
